Titanium Grade 2 Plates

Exceptional Seawater Corrosion Resistance: Outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking (SCC) in chloride environments. Titanium is immune to seawater corrosion regardless of velocity, temperature, or fouling conditions.

Superior Chloride Pitting and Crevice Corrosion Resistance: Unlike stainless steels and duplex alloys, Titanium Grade 2 exhibits no pitting or crevice corrosion in seawater and chloride-containing environments up to its maximum service temperature of 260°C (500°F).

Excellent Biofouling Resistance: Titanium Grade 2 naturally resists biofouling and marine growth, reducing maintenance requirements and preserving heat transfer efficiency over time.

Low Density – High Strength-to-Weight Ratio: Density of only 4.51 g/cm³ (approximately 57% of stainless steel and 43% of nickel alloys), providing significant weight savings in heat exchanger and vessel construction.

Excellent Resistance to Erosion and Cavitation: Titanium Grade 2 has excellent resistance to erosion and cavitation damage, making it ideal for high-velocity seawater applications (up to 20 m/s or 65 ft/s).

Excellent Heat Transfer Efficiency: Low thermal conductivity is offset by the ability to use very thin walls due to high strength-to-weight ratio, resulting in competitive overall heat transfer coefficients.

Non-Magnetic and Non-Toxic: Titanium is non-magnetic (suitable for degaussing systems) and biologically inert, making it ideal for food processing and pharmaceutical applications.

Good Weldability: Titanium Grade 2 offers good weldability with matching filler metal. Weld zones retain corrosion resistance comparable to the base metal.

Excellent Formability: Can be hot rolled and cold rolled to precise thicknesses.

International Certifications: Plates can be certified by ABS, BV, DNV, LR, GL, RINA, CCS, KR, NK for marine and shipbuilding applications, and comply with ASME, PED, and EN standards.

Titanium Grade 2 is commercially pure titanium with controlled oxygen content (0.10–0.25%) providing optimal strength and ductility. The high purity (≥98.9% Ti) and stable passive oxide film provide outstanding corrosion resistance in chloride environments.

Comparison of Seawater Corrosion Resistance:

High-Temperature Tensile Properties (Typical Values):

Maximum Recommended Service Temperatures:

Critical Note: Titanium Grade 2 has excellent resistance to seawater and chloride corrosion up to its maximum service temperature of 260°C (500°F). Above this temperature, titanium is susceptible to accelerated oxidation and embrittlement.

Heat Treatment Condition:
Titanium Grade 2 plates are normally supplied in the annealed condition (heat treated at 650–760°C) followed by air cooling. This heat treatment relieves internal stresses from rolling and restores optimum ductility and corrosion resistance.

Critical Note: Unlike stainless steels, titanium does not require rapid cooling (quenching) after annealing. Air cooling is sufficient and does not affect corrosion resistance. Titanium should not be exposed to hydrogen atelevated temperatures to prevent hydrogen embrittlement.

Delivery Condition:
Plates are normally supplied in annealed and pickled condition, providing a clean, smooth surface and excellent corrosion resistance. Bright annealed (BA) finish is also available for applications requiring ultra-clean surfaces. Upon request, mechanical polished finish can be provided.

Thickness Tolerances (Hot-Rolled – ASTM B265):

Thickness Tolerances (Cold-Rolled – ASTM B265):

Width and Length Tolerances (Hot-Rolled – ASTM B265):

Flatness Tolerances (Hot-Rolled – ASTM B265):

Titanium Grade 2 requires careful control to prevent hydrogen embrittlement:

Chemical Analysis: PMI 100% verification for Ti purity and oxygen content (0.10-0.25%).

Hydrogen Content Analysis: Verifies H ≤ 0.015% to prevent hydrogen embrittlement (critical for titanium).

Mechanical Testing: Tensile strength (≥345 MPa), yield strength (≥275 MPa), elongation (≥20%), hardness (≤200 HBW) per ASTM B265.

Dimensional Inspection: Thickness, width, length, flatness, squareness using calibrated instruments.

Surface Inspection: Visual check for surface defects, cracks, laminations, and consistency.

Ultrasonic Testing (UT): Per ASTM A435 for internal flaw detection (upon request).

Third-Party Inspection: SGS, BV, DNV, TUV, LR, ABS available upon customer request.

Marine & Shipbuilding (Seawater Cooling): Seawater-cooled heat exchanger plates, main engine cooling components, auxiliary cooling water vessels, ballast water treatment equipment, fire main system plates (ABS/BV/DNV/LR certified).

Desalination Plants: Brine heater plates, brine preheater components, multi-stage flash (MSF) evaporator shells, multi-effect distillation (MED) heat exchanger components, reverse osmosis preheater vessels, energy recovery device housings.

Offshore Platforms: Seawater cooler plates, topside heat exchanger components, subsea cooling system vessels, firewater system equipment.

Power Generation (Coastal): Coastal power plant condenser plates, cooling water heat exchanger components, auxiliary cooler vessels, nuclear power plant seawater systems.

Chemical Processing (Chloride Service): Chlor-alkali heat exchanger plates, brine heater components, wet chlorine service equipment (limited – confirm grade), hypochlorite storage tanks.

Aquaculture: Fish farm heat exchanger plates, seawater heating system components, hatchery temperature control vessels.

HVAC & Refrigeration (Coastal): Seawater-cooled chiller components, coastal air conditioning system parts, marine refrigeration heat exchanger plates.

Pulp & Paper (Bleach Plants): Chlorine dioxide service equipment (limited – confirm grade), sodium chlorate processing vessels.

Wastewater Treatment (Coastal): Brine concentrator plates, evaporator components, zero liquid discharge (ZLD) system vessels.

Food & Beverage (Coastal): Brine cooling system components, seafood processing heat exchanger plates, saltwater system equipment.

Womic Steel offers precision cutting services for Titanium Grade 2 plates:

Standard Packaging:

Plates wrapped with moisture-proof paper and VCI film

Edge protectors to prevent damage

Non-metallic spacers to prevent contamination from steel

Wooden pallets or steel skids for plate protection

Clear labeling with grade (Grade 2/UNS R50400), heat number, dimensions, weight

Womic Steel's Shipping Strengths:

Direct cooperation with global shipowners – competitive freight rates

Professional loading and securing teams using non-metallic slings prevent plate damage

Efficient document preparation (EN 10204 Type 3.1 MTR, PMI reports, hydrogen content analysis, marine classification certificates) minimizes customs delays

Continuous cargo tracking and after-sales follow-up

1. Why choose Titanium Grade 2 over Super Duplex 2507 for plate applications?
Titanium Grade 2 offers superior resistance to crevice corrosion in stagnant seawater, better performance in high-velocity seawater (up to 20 m/s vs 10 m/s), and complete immunity to chloride attack. Weight is 57% of stainless steel. For long-term submergence in seawater and high-velocity applications, titanium is preferred.

2. What is the maximum temperature for Titanium Grade 2 plates?
260°C (500°F) for continuous service in seawater/chloride environments.

3. Is Titanium Grade 2 resistant to biofouling?
Yes, titanium naturally resists biofouling and marine growth, reducing maintenance requirements and preserving heat transfer efficiency.

4. Can Titanium Grade 2 plates be used in reducing environments (no oxygen)?
Titanium Grade 2 requires some oxygen to maintain passive film. For reducing environments (no oxygen), consider Grade 7 (Ti-Pd with palladium) which we also supply upon request.

5. How is hydrogen embrittlement prevented in titanium plates?
Titanium Grade 2 plates are manufactured with hydrogen content ≤0.015%. Pickling uses specialized acids with controlled immersion time. Hydrogen content analysis reports are available upon request.

6. Are Titanium Grade 2 plates available with ASME certification?
Yes. Titanium Grade 2 plates can be supplied with ASME SB265 certification for pressure vessel applications.

Exceptional Seawater Corrosion Resistance: Immune to pitting, crevice corrosion, and SCC in seawater – no other material offers this combination

Lightweight: 57% lighter than stainless steel – reduces shipping costs and structural support requirements

Marine Certified: ABS, BV, DNV, LR, GL approvals available for shipbuilding and offshore

ASME SB265 Certified: Pressure vessel grade plates available

Excellent Biofouling Resistance: Natural resistance – no coatings required

High-Velocity Seawater Capable: Handles velocities up to 20 m/s without erosion

Non-Magnetic: Suitable for degaussing systems and sensitive instrumentation

Full Traceability: Heat number on each plate – traceable to original mill certificate

Complete Size Range: Thickness from 1mm to 50mm – standard and custom sizes

Cut-to-Size Services: Plasma, laser, waterjet, and shearing for custom dimensions

Hydrogen Content Controlled: ≤0.015% verified – prevents embrittlement

Global Delivery: Exported to major desalination, marine, and offshore projects worldwide

Tel / WhatsApp:

Victor: +86 15575100681

Jack: +86 18390957568

E-mail: info@womicstainless.com

Website: www.womicsteel.com

Contact Womic Steel today for a competitive quote on Titanium Grade 2 plates. We offer certified quality, marine classification approvals, hydrogen content verification, ASME SB265 certification, and reliable global delivery for your seawater, desalination, and marine projects.

Stock Examples (Hot-Rolled Titanium Grade 2 Plates – No.1 Finish – Seawater Grade):

Stock Examples (Cold-Rolled Titanium Grade 2 Plates – 2B Finish – High-Purity Grade):
