Inconel 600 Alloy Pipes & Tubes

Material & Grade of Inconel 600 UNS N06600 Alloy Pipes & Tubes：

Alloy Name: Inconel® 600
ASTM / ASME: Inconel 600

UNS: N06600

Werkstoff No.: 2.4816 DIN / EN: W.Nr. 2.4816

Material Type: Nickel-Chromium-Iron Alloy (Nickel-Based Alloy Steel)

Seamless Pipes & Tubes

Outer Diameter: 6 mm–630 mm (1/8"–24")

Wall Thickness: 0.8 mm–60 mm

Length: Random, Fixed Length, or as per customer request

Welded Pipes

Outer Diameter: 12 mm–1200 mm

Wall Thickness: 1.0 mm–50 mm

Custom dimensions, tight tolerances, and special requirements are available.

Standards & Specifications of Inconel 600 UNS N06600 Alloy Pipes & Tubes：

Inconel 600 / UNS N06600 Nickel-Chromium-Iron Alloy

Pipes & Tubes Standards

(Inconel 600 Seamless & Welded Pipes and Tubes)

ASTM B167 / ASME SB167 – Seamless Nickel Alloy Pipe & Tube

ASTM B163 / ASME SB163 – Heat Exchanger & Condenser Tubes

ASTM B516 / ASME SB516 – Welded Nickel Alloy Pipe

ASTM B517 / ASME SB517 – Welded Nickel Alloy Tube

ASTM B751 / ASME SB751 – General Requirements for Pipes & Tubes

ASTM B775 / ASME SB775 – Welded Nickel Alloy Pipe

ASTM B829 / ASME SB829 – General Requirements for Nickel Alloy Tube

SAE / AMS 5580 – Aerospace Nickel Alloy Tubing

DIN 17751 – Nickel Alloy Pipes & Tubes

ISO 6207 – Nickel Alloy Pipes

MIL-DTL-23227 – Military Specification for Pipes & Tubes

ASME Code Cases: 1827, N-20, N-253, N-576

Rods, Bars, Wires & Forging Stock Standards

(Inconel 600 Rod, Bar, Wire & Forged Products)

ASTM B166 / ASME SB166 – Nickel Alloy Rod, Bar & Wire

ASTM B564 / ASME SB564 – Nickel Alloy Forgings

AMS 5665 / AMS 5687 – Aerospace Nickel Alloy Bars & Forgings

BS 3075 NA14 / BS 3076 NA14 – Nickel Alloy Bars & Wires

DIN 17752 / DIN 17753 / DIN 17754 – Nickel Alloy Bars & Forgings

ISO 9723 / ISO 9724 / ISO 9725 – Nickel Alloy Bars & Wires

MIL-DTL-23229 – Military Specification (Bars & Forgings)

QQ-W-390 – Federal Specification for Nickel Alloy Wire

Plate, Sheet & Strip Standards

(Inconel 600 Plate, Sheet & Strip Products)

ASTM B168 / ASME SB168 – Nickel Alloy Plate, Sheet & Strip

ASTM B906 / ASME SB906 – General Requirements for Nickel Alloy Flat Products

AMS 5540 – Aerospace Nickel Alloy Sheets & Plates

BS 3072 NA14 / BS 3073 NA14 – Nickel Alloy Plate & Sheet

DIN 17750 – Nickel Alloy Plate & Strip

ISO 6208 – Nickel Alloy Flat Products

EN 10095 – Heat-Resisting Steel & Nickel Alloy Sheets

MIL-DTL-23228 – Military Specification for Plate & Sheet

ASME Code Cases: 1827, N-253

Fittings & Other Products Standards

(Inconel 600 Pipe Fittings & Special Products)

ASTM B366 / ASME SB366 – Nickel Alloy Pipe Fittings

DIN 17742 – Nickel Alloy Fittings

ISO 4955A – Nickel Alloy Components

AFNOR NC15Fe – French Nickel-Chromium-Iron Alloy Standard

Tensile Strength:≥550 MPa

Yield Strength (0.2%):≥240 MPa

Elongation:≥30%

Hardness:≤90 HRB

Physical Properties

Density: 8.47 g/cm³

Melting Range: 1354–1413°C

Excellent resistance to:

Chloride stress corrosion cracking

Caustic alkalis

High-temperature oxidation

The high chromium content of Inconel 600 (UNS N06600) significantly improves its resistance to oxidation compared with pure nickel, while the high nickel content provides excellent corrosion resistance under reducing environments.

This nickel-chromium-iron alloy demonstrates outstanding resistance to:

Stress corrosion cracking

Seawater and saltwater environments

Exhaust gases

Most organic acids and chemical compounds

As a result, Alloy 600 is widely used in chemical processing, marine engineering, heat treatment equipment, and high-temperature corrosive environments.

Alloy 600 is not an age-hardening alloy. Cold working is the only effective method for increasing strength.

Annealing begins at approximately 1600°F (871°C)

Full softening is typically achieved after 10–15 minutes at 1800°F (982°C)

Heating above this temperature may cause grain growth, although brief exposure at 1900°F (1038°C) can achieve complete softening without excessive grain coarsening

The cooling rate does not affect softening, therefore the material may be air cooled or water quenched after annealing.

Hot Working & Forging

Low-sulfur, reducing furnace atmospheres are recommended

Major hot working operations should be performed between 2300°F and 1850°F (1260–1010°C)

Light hot working may continue down to 1600°F (871°C)

Hot working is not recommended between 1600°F and 1200°F (871–649°C) due to reduced ductility

Proper temperature control ensures excellent forgeability and minimizes cracking risk.

Inconel 600 can be machined in both hot-worked and annealed conditions. Due to significant heat generation during machining, the following are recommended:

Tooling:

High-speed steel tools

Cemented carbide tools

Cast non-ferrous cutting tools

Typical Turning Speeds:

High-speed / non-ferrous tools: 35–45 sfm (0.18–0.23 m/s)

Cemented carbide tools: 100–175 sfm (0.51–0.89 m/s)

These values are intended as initial setup guidelines only. Actual speeds and feeds may vary depending on part geometry and machining conditions.

A sulfur-based cutting oil is recommended for lubrication; however, it must be completely removed prior to welding or high-temperature exposure.

To achieve higher mechanical properties, Alloy 600 may be cold worked below 1200°F (649°C).

Cold working increases strength while maintaining good ductility and corrosion resistance.

Inconel 600 exhibits excellent weldability and can be joined using conventional methods, including:

Gas Tungsten Arc Welding (GTAW / TIG)

Gas Metal Arc Welding (GMAW / MIG)

Shielded Metal Arc Welding (SMAW)

Brazing and soldering

Appropriate filler metals and welding procedures ensure strong, corrosion-resistant joints.

Quality Control & Testing

WOMIC Steel supplies full material certification with every shipment, including:

Chemical composition analysis

Mechanical test results (upon request)

Quality Assurance Proceduresof Inconel 600 UNS N06600 Alloy Pipes & Tubes：Visual inspection and PMI (Positive Material Identification) for all incoming materials

In-process inspection at every production stage

Production strictly according to individual customer specifications

Sample batch testing available prior to mass production (if required)

Final Inspection Includes:

Visual inspection

Dimensional verification

PMI testing

Mechanical testing (Tensile, Elongation)

Nickel Alloy Product Forms Available
Hydrostatic Test

Flattening / Flaring Test

Grain Size & Microstructure (if required)

WOMIC Steel supplies Inconel 600 / UNS N06600 nickel alloy materials in a full range of product forms:

Seamless & welded pipes

Seamless & welded tubes

Bars & rods

Wire

Plates

Sheets & strips

Forgings

Pipe fittings

Flanges

Welding rods & filler wires

Supply Capability

Single item supply or complete project bill of materials (BOM)

Small trial orders and large-volume production supported

Customized specifications, dimensions, and standards available

Inconel 600 alloy pipes and tubes are widely used in:

Chemical processing equipment

Heat exchangers & condensers

Furnace tubes & heat treatment systems

Nuclear reactor components

Aerospace & aviation systems

Marine engineering

Power generation plants

Petrochemical & refinery equipment

Professional Nickel Alloy Pipes Manufacturer & Exporter

Full compliance with ASTM / ASME / EN / DIN standards

Strict quality control & third-party inspection accepted (SGS, BV, TUV)

Rich export experience to Europe, Middle East, Asia, and South America

Competitive factory-direct pricing

Customized production & fast delivery

Manufacturing Process

Raw Material Inspection

Vacuum Induction Melting (VIM) / AOD Refining

Hot Extrusion / Cold Drawing

Solution Annealing & Heat Treatment

Straightening & Surface Finishing

NDT Inspection & Final Testing

Packing Methodof Inconel 600 UNS N06600 Alloy Pipes & Tubes：

Plastic caps on pipe ends

PVC wrapping or waterproof packing

Wooden cases or steel frames

Bundled with steel strips

Customized export packing available

Shipping Methodof Inconel 600 UNS N06600 Alloy Pipes & Tubes：

Container shipment (20FT / 40FT)

Break bulk shipment for oversized pipes

FOB / CFR / CIF / DDP available

Shipment from main Chinese ports: Shanghai, Tianjin, Qingdao

Looking for a reliable Inconel 600 pipe supplier?

Contact WOMIC Steel today for technical support, price quotation, and fast delivery solutions.
