Product Name |
Nickel Alloy Hastelloy C276 Plate, Pipes and Tubes,Nickel Alloy Hastelloy C276 Sheet,Pipes and Tubes |
|
Equivalent Grade |
Hastelloy C276,UNS N10276,AlloyC276,W.Nr. 2.4819, (NiMo16Cr15W) |
|
Standard |
GB,AISI,ASTM,DIN,EN,JIS |
|
Process |
Hot Rolled,Cold Rolled,Forged |
|
Tube Sizes |
Outer Diameter (OD): 6 mm–426 mm (1/4”–16”)
Wall Thickness (WT): 0.5 mm–30 mm |
|
Plates Sizes |
Thickness:1-100mm,Width:500-2400mm,Length:Up to 9000mm |
|
Surface Treatment |
NO.1,1D,2D,2B,NO.4,BA,HL,Mirror,Embossim,Sandblasted |
|
Fabricating |
Rolling,Bending,Sllitting,Decoiling,Cutting,Drilling,Punching,Beveling,Welding etc. |
|
Application |
Oil&Gas,Petroleum,Vessels,Ship Building,Water Treatment And Environmental Protection etc. |
EN 10204 3.1 / 3.2 Certification
ASTM B574, ASME SB574 Bar Products
ASTM B575, ASME SB575 Plate, Sheet and Strip，Nickel Alloy Plates & Sheets (raw material)
ASTM B619, ASME SB619 Welded Nickel Alloy Pipes
ASTM B622, ASME SB622 Seamless Nickel Alloy Pipes & Tubes
ASTM B626, ASME SB 626 Welded Nickel Alloy Tubes
ASTM B366, ASME SB 366 Wrought Corrosion Resistant Fittings CR HC 276, Wrought ANSI Pressure Fitting-WPHC276
ASTM B564 Forgings
AWS A 5.14, ASME SA 5.14 Welding Wire (ER NiCrMo-4)
AWS A 5.11, ASME SA 5.11 Covered Electrodes (E NiCRMo-4)
|
Hastelloy C276 |
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
Fe |
W |
V |
CO |
|
min |
- |
- |
- |
- |
- |
- |
14.5 |
15 |
4 |
3 |
- |
- |
|
max |
0.01 |
0.08 |
1 |
0.04 |
0.03 |
Bal |
16.5 |
17 |
7 |
4.5 |
0.35 |
2.5 |
A nickel-molybdenum-chromium alloy with an addition of tungsten having excellent corrosion resistance in a wide range of severe environments. The high molybdenum content makes the alloy especially resistant to pitting and crevice corrosion. The low carbon content minimizes carbide precipitation during welding to maintain corrosion resistance in as-welded structures. Used in pollution control,chemical processing,pulp and paper production and waste treatment.
|
English Item |
UNS |
W.Nr. |
JIS |
GB/T |
Other Grades |
|
Hastelloy C276 |
N10276 |
2.4819 |
NW0276 |
NS334 |
Inconel 276 |
Hastelloy C276 Physical Constants:
|
Density |
8.87 Mg/m³ |
|
Melting Range |
1325-1370 °C |
Typical Mechanical Properties
|
Material |
Ultimate Tensile (min) |
Yield Strength (Min) |
Elongation % |
Hardness Rb |
||
|
Ksi |
Mpa |
Ksi |
Mpa |
|||
|
C276 Tube |
105.4 |
727 |
45.4 |
313 |
70 |
92 |
|
C276 Plate |
107.4 |
741 |
50.3 |
347 |
67 |
89 |
|
C276 Bar |
110.0 |
758 |
52.6 |
363 |
62 |
88 |
|
C276 Sheet |
115.5 |
796 |
54.6 |
376 |
60 |
86 |
Hastelloy C276 is one of the most corrosion-resistant nickel alloys, suitable for extremely aggressive environments:
Chemical Processing Equipment
Heat Exchangers & Condensers
Oil & Gas Downhole Tubing
Flue Gas Desulfurization (FGD) Systems
Sulfuric, Hydrochloric & Phosphoric Acid Plants
Waste Incineration Systems
Marine & Offshore Engineering
Power Generation & Nuclear Industry
Alloy C276 Tube Features
Exceptional Corrosion Resistance
Alloy C276 tubing offers outstanding resistance to corrosion in extremely aggressive environments, making it ideal for applications in chemical processing, waste treatment, and pulp & paper industries.
High Strength and Toughness
Hastelloy C276 provides excellent mechanical strength and toughness, enabling it to withstand high pressures, severe stress, and elevated temperatures in demanding service conditions.
Excellent Fabricability and Versatility
C276 tubes are available in seamless and welded forms and can be easily fabricated, formed, and welded, ensuring flexibility for a wide range of industrial applications.
Wide Operating Temperature Range
Hastelloy C276 pipes and tubes perform reliably across a broad temperature range, from cryogenic temperatures to high-temperature environments, without loss of mechanical or corrosion-resistant properties.
Superior Resistance to Crevice and Pitting Corrosion
The alloy’s optimized chemical composition provides excellent resistance to crevice corrosion and pitting corrosion, effectively preventing localized attack and extending service life.
Direct Manufacturer & Exporter
Full range of ASTM / ASME / EN standards
Strict quality control & third-party inspection
Competitive factory price from China
Rich export experience to Middle East, Europe, Southeast Asia
Custom sizes & special requirements supported
Fast production & reliable delivery schedule
Raw Material Inspection (Nickel Alloy Billet / Plate)
Hot Extrusion / Cold Drawing / Cold Rolling
Solution Annealing Heat Treatment
Straightening & Sizing
Non-Destructive Testing (UT / ECT)
Final Inspection & Marking
Packing & Export Preparation
Plastic caps on both ends
Individual PVC wrapping
Wooden cases / steel crates
Bundled with steel strips
Export seaworthy packing
Customer logo & special marking available
Shipping Methods:
Sea Freight (FCL / LCL)
Air Freight
Express (for small quantity)
Delivery Terms:
FOB / CFR / CIF / DDP
Main Ports: Shanghai, Ningbo, Tianjin
Email: info@womicstainless.com
Website: www.womicstainless.com
Please feel free to contact us for Hastelloy C276 pipe price, technical datasheet, mill test certificate (MTC), or customized solutions. Our professional sales and technical team will respond within 24 hours.
